gpt Struct Reference
GUID partition table (GPT) stored in disk sector 1+/last-. More...
#include <gpt.hpp>
Public Member Functions | |
| struct | __packed (header_fields) |
| GUID partition table header defined fields. | |
| struct | __packed (header) |
| GUID partition table header stored in sector 1/last. | |
| static_assert (sizeof(header)==HEADER_SIZE,"wrong header size") | |
| static_assert (sizeof(header)<=512,"header size must be smaller than or equal to a sector") | |
| static_assert ((512%sizeof(header))==0,"wrong header size") | |
| struct | __packed (entry) |
| GUID partition table entry stored in the sectors following the header. | |
| static_assert ((512%sizeof(entry))==0,"wrong entry size") | |
Static Public Attributes | |
| static const uint64_t | SIGNATURE = 0x5452415020494645ull |
| static const uint32_t | REVISION = 0x00010000ul |
| static const uint16_t | HEADER_SIZE = 128 |
Detailed Description
GUID partition table (GPT) stored in disk sector 1+/last-.Member Function Documentation
| struct gpt::__packed | ( | header_fields | ) | [inline, read] |
GUID partition table header defined fields.
< GPT signature to signify a valid GPT.
< EFI specification revision.
< GPT header size (usually 128).
< GPT header CRC32 checksum.
< GPT reserved/undefined word.
< This GPT header's sector number.
< Alternate GPT header's sector number.
< First usable sector on disk.
< Last usable sector on disk.
< This disk's globally unique ID.
< Sector containing the first partition entry.
< Number of partition table entries.
< A partition table entry's size.
< Partition table CRC32 checksum.
| struct gpt::__packed | ( | header | ) | [inline, read] |
GUID partition table header stored in sector 1/last.
Filler to pad & align the data structure
Default constructor for array construction. All attributes are set to zero.
Initializing constructor. All missing attributes are set to zero.
| struct gpt::__packed | ( | entry | ) | [inline, read] |
GUID partition table entry stored in the sectors following the header.
< Partition type globally unique ID.
< Partition globally unique ID.
< Partition start in LBA addressing.
< Partition end in LBA addressing.
< Partition attributes.
Partition name. 36 unicode (wide) characters.
Default constructor for array construction. All attributes are set to zero.
Initializing constructor. All missing attributes are set to zero.
References efi::is_null_guid().
The documentation for this struct was generated from the following file:
