uart_registers Struct Reference
Struct containing all UART 8250/16450 internal registers.
More...
#include <uart_registers.hpp>
List of all members.
|
Public Types |
| enum | interrupt_ids {
RECEIVED_ERROR = 0x03,
RECEIVED_DATA_AVAILABLE = 0x02,
TRIGGER_LEVEL_IDENTIFICATION = 0x06,
THR_EMPTY = 0x01,
MODEM_STATUS_CHANGE = 0x00
} |
Static Public Member Functions |
|
static const char * | register_name (const uint8_t offset) |
Public Attributes |
|
uint8_t | rbr |
|
uint8_t | thr |
|
union uart_registers::ier | ier |
|
uint16_t | divisor_latch |
|
union uart_registers::iir | iir |
|
union uart_registers::lcr | lcr |
|
union uart_registers::mcr | mcr |
|
union uart_registers::lsr | lsr |
|
union uart_registers::msr | msr |
|
uint8_t | scr |
Classes |
| union | ier |
| union | iir |
| union | lcr |
| union | lsr |
| union | mcr |
| union | msr |
Detailed Description
Struct containing all UART 8250/16450 internal registers.
An exact memory layout is not required. However the registers itself must be defined as the standard describes.
The documentation for this struct was generated from the following file:
