pci_device Struct Reference
Interface for PCI devices. More...
#include <pci_device.hpp>
Public Member Functions | |
| virtual | ~pci_device (void) |
| Empty virtual destructor to enforce derived virtual destructors. | |
| virtual const char * | name (void) const =0 |
| Returns the device's name. | |
| virtual int | reset (void)=0 |
| Resets the device's state and all writable PCI configuration space values back to defaults as when powering up the machine. | |
| virtual const pci_ioregion * | get_ioregion (uint8_t region_num) const =0 |
| Returns a device's I/O region by its index or NULL, if the index is invalid. | |
| virtual const search_result | search_ioregion (enum pci_ioregion::type type, l4_gpa_t base, l4_gpa_t size=1) const =0 |
| Searchs an I/O region and returns it in a search_result struct. | |
| virtual const pci_config_header64 & | get_config_space (void) const =0 |
| Returns a device's PCI configuration space. | |
| virtual l4_umword_t | read_config_space (pci_config_header16::offset_t offset, access_size access_size)=0 |
| Emulates a device's PCI configuration space read access and returns the value that should have been read. | |
| virtual int | write_config_space (pci_config_header16::offset_t offset, l4_umword_t data, access_size access_size)=0 |
| Emulates a device's PCI configuration space write access. | |
Static Public Member Functions | |
| static const char * | class_name (void) |
| Returns the class' name to generate customized log messages in templates. | |
Classes | |
| struct | search_result |
| Result type for search region functions. More... | |
Detailed Description
Interface for PCI devices.Defines everything a PCI bridge needs to know about a PCI device.
Member Function Documentation
| virtual const search_result pci_device::search_ioregion | ( | enum pci_ioregion::type | type, | |
| l4_gpa_t | base, | |||
| l4_gpa_t | size = 1 | |||
| ) | const [pure virtual] |
Searchs an I/O region and returns it in a search_result struct.
base & size are I/O space addresses or guest physical addresses depending on the type to search for.
Implemented in pci_device_base< SpaceT >, pci_device_base< l4io_device_config_space >, pci_device_base< piix_ide_config_space >, and pci_device_base< dummy_device_config_space >.
| virtual l4_umword_t pci_device::read_config_space | ( | pci_config_header16::offset_t | offset, | |
| access_size | access_size | |||
| ) | [pure virtual] |
Emulates a device's PCI configuration space read access and returns the value that should have been read.
This function is intended to be overridden.
Implemented in i440fx_host_bridge, pci_device_base< SpaceT >, l4io_device, pci_device_base< l4io_device_config_space >, pci_device_base< piix_ide_config_space >, and pci_device_base< dummy_device_config_space >.
| virtual int pci_device::write_config_space | ( | pci_config_header16::offset_t | offset, | |
| l4_umword_t | data, | |||
| access_size | access_size | |||
| ) | [pure virtual] |
Emulates a device's PCI configuration space write access.
This function is intended to be overridden.
Implemented in i440fx_host_bridge, pci_device_base< SpaceT >, dummy_device, l4io_device, piix_ide, pci_device_base< l4io_device_config_space >, pci_device_base< piix_ide_config_space >, and pci_device_base< dummy_device_config_space >.
The documentation for this struct was generated from the following file:
