device_base Struct Reference
Base class implementing the device interface along with iospace_handler, mmio_handler, and irq_source. More...
#include <device_base.hpp>
Public Member Functions | |
| device_base (machine_base &machine, const string &device_name) | |
| virtual uint32_t | read_ioport (l4_port_t port, access_size access_size) |
| Stub implementation, which always returns an invalid value. | |
| virtual int | write_ioport (l4_port_t port, uint32_t data, access_size access_size) |
| Stub implementation, which always returns -L4_ENOTSUPP. | |
| virtual l4_umword_t | read_mmio (l4_gpa_t address, access_size access_size) |
| Stub implementation, which always returns an invalid value. | |
| virtual int | write_mmio (l4_gpa_t address, l4_umword_t data, access_size access_size) |
| Stub implementation, which always returns -L4_ENOTSUPP. | |
| virtual l4_hva_t | map_mmio_region (int flags, l4_gpa_t base, l4_gpa_t size=1) |
| Stub implementation, which always returns an invalid value (0). | |
| virtual int | unmap_mmio_region (l4_gpa_t base, l4_gpa_t size=1) |
| Stub implementation, which always returns -L4_ENOTSUPP. | |
| virtual void | irq_moved (l4_irq_t from, l4_irq_t to) |
| Called whenever the IRQ management chooses to assign this device annother IRQ than the requested one. | |
| virtual const char * | name (void) const |
| Returns the device's name. | |
| virtual int | reset (void) |
| Resets the device's state back to defaults as when powering up the machine. | |
Static Public Attributes | |
| static const bool | VERBOSE_ALLOCATION = false |
Protected Member Functions | |
| virtual int | use_iospace (l4_port_t base, l4_port_t size=1, bool verbose=VERBOSE_ALLOCATION) |
| Allocates the specified I/O space region by registering itself as handler. | |
| virtual int | change_iospace (iospace_manager::ioport_flags use, l4_port_t base, l4_port_t size=1, bool verbose=VERBOSE_ALLOCATION) |
| Changes the specified I/O space region to the desired state. | |
| virtual int | free_iospace (l4_port_t base, l4_port_t size=1, bool verbose=VERBOSE_ALLOCATION) |
| Frees the specified I/O space region by unregistering itself. | |
| virtual int | use_iomemory (l4_gpa_t base, l4_gpa_t size=1, bool verbose=VERBOSE_ALLOCATION) |
| Allocates the specified I/O memory region by registering itself as handler. | |
| virtual int | free_iomemory (l4_gpa_t base, l4_gpa_t size=1, bool verbose=VERBOSE_ALLOCATION) |
| Frees the specified I/O memory region by unregistering itself. | |
| virtual int | use_irq (irq_manager::irq_flags use=irq_manager::VIRTUAL, l4_irq_t requested_irq=irq_manager::NO_IRQ, l4_irq_t physical_irq=irq_manager::NO_IRQ, bool verbose=VERBOSE_ALLOCATION) |
| Allocate an IRQ for the specified usage. | |
| void | assert_irq (void) const |
| Assert the (previously allocated) IRQ. | |
| virtual int | free_irq (bool verbose=VERBOSE_ALLOCATION) |
| Free the (previously allocated) IRQ. | |
Protected Attributes | |
| const string | device_name |
| The device's name returned by name(). | |
| machine_base & | machine |
| Reference to the machine object this device belongs to. | |
| l4_irq_t | irq |
| Allocated IRQ, if applicable. | |
Detailed Description
Base class implementing the device interface along with iospace_handler, mmio_handler, and irq_source.Member Function Documentation
| virtual uint32_t device_base::read_ioport | ( | l4_port_t | port, | |
| access_size | access_size | |||
| ) | [inline, virtual] |
Stub implementation, which always returns an invalid value.
Implemented here as a dummy to avoid unnecessary overriding in descendant classes. This function is intended to be overridden.
Implements iospace_handler.
Reimplemented in uart, l4io_device, and piix_ide.
References iospace_handler::INVALID, and name().
| virtual int device_base::write_ioport | ( | l4_port_t | port, | |
| uint32_t | data, | |||
| access_size | access_size | |||
| ) | [inline, virtual] |
Stub implementation, which always returns -L4_ENOTSUPP.
Implemented here as a dummy to avoid unnecessary overriding in descendant classes. This function is intended to be overridden.
Implements iospace_handler.
Reimplemented in uart, l4io_device, and piix_ide.
References name().
| virtual l4_umword_t device_base::read_mmio | ( | l4_gpa_t | address, | |
| access_size | access_size | |||
| ) | [inline, virtual] |
Stub implementation, which always returns an invalid value.
Implemented here as a dummy to avoid unnecessary overriding in descendant classes. This function is intended to be overridden.
Implements mmio_handler.
References mmio_handler::INVALID, and name().
| virtual int device_base::write_mmio | ( | l4_gpa_t | address, | |
| l4_umword_t | data, | |||
| access_size | access_size | |||
| ) | [inline, virtual] |
Stub implementation, which always returns -L4_ENOTSUPP.
Implemented here as a dummy to avoid unnecessary overriding in descendant classes. This function is intended to be overridden.
Implements mmio_handler.
References name().
| virtual l4_hva_t device_base::map_mmio_region | ( | int | flags, | |
| l4_gpa_t | base, | |||
| l4_gpa_t | size = 1 | |||
| ) | [inline, virtual] |
Stub implementation, which always returns an invalid value (0).
Implemented here as a dummy to avoid unnecessary overriding in descendant classes. This function is intended to be overridden.
Implements mmio_handler.
Reimplemented in pci_device_base< SpaceT >, l4io_device, pci_device_base< l4io_device_config_space >, pci_device_base< piix_ide_config_space >, and pci_device_base< dummy_device_config_space >.
References name().
| virtual int device_base::unmap_mmio_region | ( | l4_gpa_t | base, | |
| l4_gpa_t | size = 1 | |||
| ) | [inline, virtual] |
Stub implementation, which always returns -L4_ENOTSUPP.
Implemented here as a dummy to avoid unnecessary overriding in descendant classes. This function is intended to be overridden.
Implements mmio_handler.
Reimplemented in pci_device_base< SpaceT >, l4io_device, pci_device_base< l4io_device_config_space >, pci_device_base< piix_ide_config_space >, and pci_device_base< dummy_device_config_space >.
References name().
| virtual void device_base::irq_moved | ( | l4_irq_t | from, | |
| l4_irq_t | to | |||
| ) | [inline, virtual] |
Called whenever the IRQ management chooses to assign this device annother IRQ than the requested one.
Updates the stored IRQ.
Implements irq_source.
Reimplemented in pci_device_base< SpaceT >, pci_device_base< l4io_device_config_space >, pci_device_base< piix_ide_config_space >, and pci_device_base< dummy_device_config_space >.
Referenced by pci_device_base< dummy_device_config_space >::irq_moved().
| virtual int device_base::use_iospace | ( | l4_port_t | base, | |
| l4_port_t | size = 1, |
|||
| bool | verbose = VERBOSE_ALLOCATION | |||
| ) | [inline, protected, virtual] |
Allocates the specified I/O space region by registering itself as handler.
Override read_ioport and write_ioport to implement the desired functionality.
References machine, and iospace_manager::register_iospace_handler().
Referenced by pci_device_base< SpaceT >::ioregion_relocated().
| virtual int device_base::use_iomemory | ( | l4_gpa_t | base, | |
| l4_gpa_t | size = 1, |
|||
| bool | verbose = VERBOSE_ALLOCATION | |||
| ) | [inline, protected, virtual] |
Allocates the specified I/O memory region by registering itself as handler.
Override read_mmio and write_mmio to implement the desired functionality.
References machine, and memory_manager::register_mmio_handler().
Referenced by pci_device_base< SpaceT >::ioregion_relocated().
| virtual int device_base::use_irq | ( | irq_manager::irq_flags | use = irq_manager::VIRTUAL, |
|
| l4_irq_t | requested_irq = irq_manager::NO_IRQ, |
|||
| l4_irq_t | physical_irq = irq_manager::NO_IRQ, |
|||
| bool | verbose = VERBOSE_ALLOCATION | |||
| ) | [inline, protected, virtual] |
Allocate an IRQ for the specified usage.
The virtual IRQ is returned and additionally stored as attribute irq. Negative values denote error conditions.
Reimplemented in pci_device_base< SpaceT >, pci_device_base< l4io_device_config_space >, pci_device_base< piix_ide_config_space >, and pci_device_base< dummy_device_config_space >.
References machine, irq_manager::NO_IRQ, and irq_manager::register_irq().
Referenced by pci_device_base< dummy_device_config_space >::use_irq().
| void device_base::assert_irq | ( | void | ) | const [inline, protected] |
Assert the (previously allocated) IRQ.
This function is not intended to be overridden.
References irq_manager::assert_irq(), and machine.
Member Data Documentation
machine_base& device_base::machine [protected] |
Reference to the machine object this device belongs to.
Used to request/free resources.
Referenced by assert_irq(), change_iospace(), free_iomemory(), free_iospace(), free_irq(), use_iomemory(), use_iospace(), and use_irq().
The documentation for this struct was generated from the following file:
